Don't know it's dynamics or even if it will work.
Anybody for a Meshed-Coil?
- Thread starter Crystal Valley Clouds
- Start date
-
- Tags
- coil build for rta
can’t see why it won’t work.Don't know it's dynamics or even if it will work.
I got 2 rolls of mesh I think laying around. Gonna try this out.
the toughest part will be to keep the mesh in the coil while wicking it.
The good thing would be that if you wick hard you won't get the dreaded mesh dry burn. The round wire will allow you to wick harder by keeping the mesh in place.
Took that into mind, but I will update everyone once I got the multiple builds done and tested. That is though when and if I can find my mesh
This will be my rubble to walk over, but I'm going to play around with our microstamper and bending tools and their mods. Experimenting is really fun. Made a once off vertical quad-coil on a double-coil deck using 26GA Ni80 with all coils heating evenly and it gave nice clouds and flavor, but wicking that thing took ages so I stopped using it.
Will work...
wick through a straw.
wick through a straw.
Took that into mind, but I will update everyone once I got the multiple builds done and tested. That is though when and if I can find my mesh
So..
I used SS316L 100mesh 1.12ohm per-ft pieces inside x2 SS316L 24Ga 3mm coils with 3 loops spaced. It vapes as smooth as butter, but I don't think it will last as long as normal coil and wick though. Flavor is so intense it's like using one of those high quality ceramic coils.
I used SS316L 100mesh 1.12ohm per-ft pieces inside x2 SS316L 24Ga 3mm coils with 3 loops spaced. It vapes as smooth as butter, but I don't think it will last as long as normal coil and wick though. Flavor is so intense it's like using one of those high quality ceramic coils.
So...in reality, what does it look like?
So..
I used SS316L 100mesh 1.12ohm per-ft pieces inside x2 SS316L 24Ga 3mm coils with 3 loops spaced. It vapes as smooth as butter, but I don't think it will last as long as normal coil and wick though. Flavor is so intense it's like using one of those high quality ceramic coils.
A more practical idea for a mesh coil with added juice retention properties - no cotton needed.
So the biggest hurdle is needing a wire with less resistance than the entire mesh loop. Now rhis might cause a huge diameter of the entire setup and it might not fit in most decks. But also @CaliGuy has shown a massively efficient and great setup using mesh
If your using the mesh as part of the coil then this should be fine the way you did it.
if your using the mesh as a wick extension then oxidise the mesh first
if your using the mesh as a wick extension then oxidise the mesh first
So the biggest hurdle is needing a wire with less resistance than the entire mesh loop. Now rhis might cause a huge diameter of the entire setup and it might not fit in most decks. But also @CaliGuy has shown a massively efficient and great setup using mesh
